TP-Link TL-SG1210MP 10-Port Gigabit Desktop Switch with 8-Port PoE+PORT: 8× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 1× Combo Gigabit SFP SlotS

Overview

TP-Link TL-SG1210MP 10-Port Gigabit Desktop Switch with 8-Port PoE+ • 9× gigabit RJ45 ports, and 1× gigabit combo SFP/RJ45 Port • 8× PoE+ ports transfer data and power via a single cable with a total power budget of 123 W* • Compliance with IEEE 802.3af/at PoE+, the switch supports PoE Power up to 30 W for each PoE port • Up to 250 m data and power transmission range under Extend Mode** • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive applications • Isolation Mode allows one-click client traffic separation for higher security and performance • Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery. • Plug and play with no configuration required • Fanless design reduces power consumption and works silently in its location HARDWARE FEATURES Interface • 9× 10/100/1000 Mbps RJ45 Ports • 1× 1000 Mbps Combo SFP/RJ45 Port • AUTO Negotiation • AUTO MDI/MDIX Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) Fan Quantity Fanless Physical Security Lock Yes External Power Supply External Power Adapter (Output: 53.5VDC / 2.43A) Packet Forwarding Rate 14.88 Mpps PoE Ports (RJ45) • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 123 W Mac Address Table 4K Jumbo Frame 16 KB Switching Capacity 20 Gbps Dimensions ( W x D x H ) 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) Max Power Consumption • 7.93 W (220V / 50Hz with no PD connected) • 141.40 W (220V / 50Hz with 123 W PD connected) Max Heat Dissipation • 27.04 BTU/h (220V / 50Hz with no PD connected) • 482.17 BTU/h (220V / 50Hz with 123 W PD connected) SOFTWARE FEATURES Transmission Method Store-And-Forward Advanced Functions • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data tra
